J599A8（ARINC801）series optical fiber connector，

Brand Name : HIGH WOOD

Model Number : J599A8（ARINC801）

Certification : AS9001

Place of Origin : China

MOQ : 100pcs

Price : 10$-150$

Payment Terms : T/T, L/C, Western Union

Supply Ability : 100，000pcs per month

Delivery Time : 2-9weeks

Packaging Details : Standard export package

Plating : Stainless steel passivation

Type of connector : Plug

Temperature : -55℃ ~ +125℃

Endurance : 500 cycles

Insertion loss : ≤0.6dB

Salt spray : 500h

Contact Now

J599A8(ARINC801)

  • The interface size conforms to GJB599B(MIL-DTL-38999) Ⅲ series, and the performance conforms to ARINC801 standard
  • Suitable for aeronautical, electronic, shipboard and other systems for multi-channel optical communication
  • Adopts standard 1.25mm ceramic pin for high docking accuracy
  • Ceramic casing package array, can be disassembled and replaced as a whole, easy to use and maintain
  • Install and remove tool M81969/14-03 for contact parts, easy to operate

How to order:

J599A8（ARINC801）series optical fiber connector，

Product pictures:

J599A8（ARINC801）series optical fiber connector，J599A8（ARINC801）series optical fiber connector，J599A8（ARINC801）series optical fiber connector，

Environmental:

Temperature :

-55℃ ~ +125℃

Salt spray:

ClassK,W:500h

ClassF:48h

Class MW: 192h (acidic atmosphere)
Air tightness (suitable for airtight switching socket): gas leakage rate ≤1×10-9Pa.m3/s, internal
and external pressure difference of 1 atmosphere

Mechanical:

Tensile force:: ≥68N (2mm contact jumper)
Endurance: 500 cycles
Vibration:

10Hz ~ 2000Hz, powerspectral density 0.4G²/Hz, acceleration
root mean square value 23.1G
Impact: Peak acceleration 2940m/s²,duration 3ms,Velocity change rate5.61m/s

Optical performance​:

Insertion loss: ≤0.6dB
RL (return loss): ≥ 20dB@850nm；
≥ 40dB@1310nm

Plug dimensions:

J599A8（ARINC801）series optical fiber connector，

Contact arrangement (take plug surface as an example):

J599A8（ARINC801）series optical fiber connector，

17-08
